Articles
What's the seatpost wedge torque on the ABLE?
The ALLIED internal seatpost wedge has a torque spec of 5Nm. Be sure to apply carbon paste to the seatpost before installing it for the first time.
What size tires can I run on the ABLE?
The ABLE was designed to ride best with high-volume gravel racing tires. It is compatible with tires up to 57mm measured width, and we recommend a minimum of 45mm due to the handling characteristics. Note: tire manufacturers measure differently, so i
What headset does the ABLE use?
Wolftooth Premium IS41/52 with a custom dust-cap and spacers to match our STO3 stem design. If you are running a standard externally routed stem, it will also accommodate any IS41/52 headset like Chris King Dropset 3.
Where is the ABLE made?
The ABLE frame was designed, prototyped and fully tested in-house at our factory in Rogers, AR. The carbon lay-up and molding on the frame and fork take place at an external factory based in Asia. Each raw carbon part produced at the external facto
Can I use a front derailleur on the ABLE?
No, the ABLE frame is purposely designed for 1x to maximize tire clearance with the shortest chainstay possible.
Can I use a suspension fork on the ABLE?
Yes, it can fit gravel-specific forks from Rockshox, Fox, and Cane Creek. You will need to use a standard stem and ported Eagle cable guide. Keep in mind, most suspension forks will limit tire clearance per the recommendation of the fork manufacture
Are the tires setup tubeless?
Yes, all of our complete bikes ship set up tubeless with Silca sealant, ready to ride!
What front chainring can I fit on the ABLE?
Up to 50 tooth in the front using a SRAM Wide, or GRX 1x cranksets.
Can I get custom paint on my ABLE?
Yes! Please select 'Custom' for the paint option when you purchase your ABLE, and we will follow up to confirm what paint option you are looking for. Keep in mind, $1,250 is the starting price for custom paint, which covers the cost of matching most
How does the ST03 internal stem work?
Check out the ST03 video tutorial below. ALLIED Stem ST03 Tutorial
Do I have to use Allied's ST03 stem with internal cable routing on the ABLE?
To run your brake lines fully internal or hidden, you will need to use our ST03 stem with a compatible handlebar. For those who prefer to let the cables breathe a little, we also offer a version of the ABLE with externally routed ABLE fork for the fr
What handlebars can I run with the ST03 stem?
Most internally routed handlebars work well on the ST03 stem. Specifically search for bars that say they are compatible with the ACR/ICR system, or the ENVE In-Route system. Other bars with a routing port on the backside of the clamp should work as w
Can I use a mechanical drivetrain on the ABLE?
No, the ABLE is designed for wireless electronic drivetrains only, with or without our internal stem.
What bottom bracket standard does the ABLE use?
68mm English Threaded, also referred to as BSA by some manufacturers.
Where can I find technical docs for ABLE, ST03 stem and SPO2 seapost?
Please find the information in the links below:. ALLIED ABLE FS09 Frameset Exploded. ALLIED ABLE FS09 Storage Box Assembly. ALLIED ST03 Stem Exploded. ALLIED SP02 Seatpost Exploded
Do you make a chain guide for the ABLE?
No, we do not make a chain guide for the ABLE at this time.
What build options are available on the ABLE?
We offer a range of build kit options from many of our favorite brands. To view those options and customize your dream build, click on "Customize Your Build" located beneath the paint menu. Pricing will update in real time as you select different com
What size brake rotors does the ABLE use?
The ABLE is designed for 160mm rotors front and rear.
